395
RS-485 Communication Features
• When PowerOn Resume (COM-96) is set to ‗yes‘, value is saved even if the power of the
inverter is disconnected. When PowerOn Resume (COM-96) is set to ‗no‘, value is not
saved if the power of the inverter is disconnected.
• A value higher than the maximum frequency (DRV-20) cannot be used. The maximum
frequency can be set by using the keypad. This value can be used when Freq Ref Src
(DRV-07) is set to ‗Int 485‘.
• AV2, AV3 and AV4 are used to provide acceleration/deceleration rate and frequency
reference commands. These can be written in AUTO mode only.
7.4.5.2 Multi-state Value Object Instance
Instance ID
Object Name
Description
Setting Range
Units
R/W
MSV1
LostCommand
Command lost
operation setting
0: None
1: FreeRun
2: Dec
3: HoldInput
4: HoldOutput
5: LostPreset
MSG
R/W
7.4.5.3 Binary Value Object Instance
Instance ID
Object Name
Description
Active /Inactive Text
R/W
BV1
StopCmd
Stop command
False/True
R/W
BV2
RunForwardCmd
Run forward command
False/True
R/W
BV3
RunReverseCmd
Run reverse command
False/True
R/W
BV4
ResetFaultCmd
Fault reset command
False/True
R/W
BV5
FreeRunStopCmd
Free run stop
command
False/True
R/W
BV6
Relay1Cmd
Relay 1 On/Off
command
False/True
R/W
BV7
Relay2Cmd
Relay 2 On/Off
command
False/True
R/W
BV8
Relay3Cmd
Relay 3 On/Off
command
False/True
R/W
