Table of Functions
416
disabled
Code
Comm.
Addres
s
Name
LCD Display
Setting Range
Initial
Value
Property*
Ref.
00
-
Jump
Code
Jump Code
1-99
24
O
p.65
01
0h1301
Accelerati
on pattern
Acc Pattern
0
Linear
0: Linear
Δ
p.117
02
0h1302
Decelerati
on pattern
Dec Pattern
1
S-curve
Δ
p.117
03
16
0h1303
S-curve
accelerati
on start
point
gradient
Acc S Start
1–100 (%)
40
Δ
p.117
04
0h1304
S-curve
accelerati
on end
point
gradient
Acc S End
1–100 (%)
40
Δ
p.117
05
17
0h1305
S-curve
decelerati
on start
point
gradient
Dec S Start
1–100 (%)
40
Δ
p.117
06
0h1306
S-curve
decelerati
on end
point
gradient
Dec S End
1–100 (%)
40
Δ
p.117
07
0h1307
Start
Mode
Start Mode
0
Acc
0: Acc
Δ
p.128
1
DC-
Start
08
0h1308
Stop
Mode
Stop Mode
0
Dec
0: Dec
Δ
p.129
1
DC-
Brake
16
ADV-03–04 are displayed when ADV-01 is set to ‗1 (S-curve)‘.
17
ADV-05–06 are displayed when ADV-02 is set to ‗1 (S-curve)‘.
