Bipolar: -10–10 V(±12 V Max)
Voltage/current input for
frequency reference
input
Used to setup or modify a frequency
reference via analog voltage or current
input terminals.
Switch between voltage (V2) and current
(I2) modes using a control board switch
(SW4).
Input current: 0–20 mA
Maximum Input current: 24 mA
Input resistance 249 Ω
Pulse input for frequency
reference input (pulse
train)
Setup or modify frequency references
using pulse inputs from 0 to 32 kHz.
Low Level: 0–0.8 V, High Level: 3.5–12 V
Output/Communication Terminal Labels and Descriptions
Used to send inverter output information to
external devices: output frequency, output current,
output voltage, or a DC voltage.
Operate switch (SW5) to select the signal output
type (voltage or current) at the AO terminal.
Output Signal Specifications:
Output voltage: 0–10 V
Maximum output voltage/current: 12 V/10 mA
Output current: 0–20 mA
Maximum output current: 24 mA
Factory default output: Frequency
Multi-function
(Open Collector)
Pulse Output
Selects a multi-function output signal or pulse
output, output frequency, output current, output
voltage, DC voltage by selecting one of the
output.
DC 26 V, 50 mA or less
Pulse output terminal
Output frequency: 0–32 kHz
Output voltage: 0–12 V
Common ground contact for an open collector
(with external power source)
-Maximum output current: 100 mA
-Do not use this terminal for any purpose other
than supplying power to a PNP mode circuit
