Technical Specification
544
Three Phase 400 V (0.75–3.7 kW)
Model H100–4
0008
0015
0022
0037
Applied Motor
HP
1.0
2.0
3.0
5.0
kW
0.75
1.5
2.2
3.7
Rated
output
Rated Capacity (kVA)
1.9
3.0
4.5
6.1
Rated
Current (A)
Three-Phase
2.5
4
6
8
Single-
Phase
1.6
2.4
3.5
4.6
Output Frequency
0–400 Hz
Output Voltage (V)
3-Phase 380–480 V
Rated
input
Working
Voltage (V)
Three-
Phase
3-Phase 380–480 VAC (-15%–+10%)
Single-
Phase
1-Phase 480 VAC (-5%–+10%)
Input
Frequency
Three-
Phase
50–60 Hz (5%)
Single-
Phase
60 Hz(5%)
Rated Current (A)
2.4
4.2
6.5
8.7
Weight (kg)
3.3
3.3
3.3
3.3
• The standard motor capacity is based on a standard 4-pole motor.
• The standard used for 200 V inverters is based on a 220 V supply voltage, and 400 V
inverters are based on a 440 V supply voltage.
• The rated output current is limited based on the carrier frequency set at CON-04.
