11-9
Address Parameter Scale Unit R/W Data value
0x000C DC Link voltage 0.1 V R
See Function List.
0x000D Output power 0.1 kW R
0x000E Inverter status R
BIT 0: Stop
BIT 1: Forward running
BIT 2: Reverse running
BIT 3: Fault (Trip)
BIT 4: Accelerating
BIT 5: Decelerating
BIT 6: speed arrival
BIT 7: DC Braking
BIT 8: Stopping
Bit 9: not Used
BIT10: Brake Open
BIT11: Forward run command
BIT12: Reverse run command
BIT13: REM. R/S
BIT14: REM. Freq.
0x000F Trip information R
BIT 0: OCT
BIT 1: OVT
BIT 2: EXT-A
BIT 3: EST (BX)
BIT 4: COL
BIT 5: GFT (Ground Fault)
BIT 6: OHT (Inverter overheat)
BIT 7: ETH (Motor overheat)
BIT 8: OLT (Overload trip)
BIT 9: HW-Diag
BIT10: EXT-B
BIT11: EEP (Parameter Write Error)
BIT12: FAN (Lock & Open Error)
BIT13: PO (Phase Open)
BIT14: IOLT
BIT15: LVT
0x0010 Input terminal status R
BIT 0: P1
BIT 1: P2
BIT 2: P3
BIT 3: P4
