2
z Input & output ratings: Three Phase 400V Class
SV ■■■ iG5A – 4 ■■
004 008 015 022 037 040 055 075 110 150 185 220
Max capacity
[HP] 0.5 1 2 3 5 5.4 7.5 10 15 20 25 30
[kW] 0.4 0.75 1.5 2.2 3.7 4.0 5.5 7.5 11 15 18.5 22
Output
ratings
Capacity [kVA]
2
0.95 1.9 3.0 4.5 6.1 6.9 9.1 12.2 18.3 22.9 29.7 34.3
FLA [A]
3
1.25 2.5 4 6 8 9 12 16 24 30 39 45
Max
Frequency
400 [Hz]
4
Max Voltage 3Φ 380 ~ 480V
5
Input
ratings
Rated Voltage 3Φ 380 ~ 480 VAC (+10%, -15%)
Rated
Frequency
50 ~ 60 [Hz] (±5%)
Cooling method N/C Forced cooling
Weight [kg] 0.76 0.77 1.12 1.84
1.8
9
1.89 3.66 3.66
9.
0
9.0 13.3 13.3
1) Indicates the maximum applicable motor capacity when using a 4-pole standard motor.
2) Rated capacity is based on 220V for 200V class and 440V for 400V class.
3) Refer to 13-4 when Carrier frequency setting (H39) is above 3kHz.
4) Max frequency setting range is extended to 300Hz when H40 (Control mode select) is set to 3
(Sensorless vector control).
5) Maximum output voltage cannot be higher than the input voltage. It can be programmable below
input voltage.
6) N/C: Natural Convention
z Control
Control method V/F, Sensorless vector control
Frequency setting resolution
Digital command: 0.01Hz
Analog command: 0.06Hz (Max freq.: 60Hz)
Frequency accuracy
Digital command: 0.01% of Max output frequency
Analog command: 0.1% of Max output frequency
V/F pattern Linear, Squared, User V/F
Overload capacity 150% per 1 min.
Torque boost Manual/Auto torque boost
Dynamic
Braking
Max braking
torque
20%
1)
Time/%ED 150%
2) when using optional DB resistor
1) Means average braking torque during Decel to stop of a motor.
2) Refer to page 13-8 for DB resistor specification.
To Next Page
