LSIS SV-iG5A Series User Manual

3
z Operation
Operation mode
Keypad/ Terminal/ Communication option/ Remote keypad
selectable
Frequency setting
Analog: 0 ~ 10[V], -10 ~ 10[V], 0 ~ 20[mA]
Digital: Keypad
Operation features PID, Up-down, 3-wire
Input
Multi-function terminal
P1 ~ P8
NPN / PNP selectable (See page 2-13)
FWD/REV RUN, Emergency stop, Fault reset,
Jog operation, Multi-step Frequency-High, Mid, Low, Multi-step
Accel/Decel-High, Mid, Low, DC braking at stop, 2
nd
motor
select, Frequency UP/Down, 3-wire operation, External trip A, B,
PID-Inverter (v/f) operation bypass, Option-inverter (v/f)
operation bypass, 2
nd
Source, Analog Hold, Accel/Decel stop,
Up/Down Save Freq, Jog FX/RX
Output
Open collector terminal
Fault output and
inverter status output
Less than DC 24V 50mA
Multi-function relay
(N.O., N.C.) Less than AC250V 1A,
Less than DC 30V 1A
Analog output
0 ~ 10 Vdc (less than10mA): Output Freq, Output Current,
Output Voltage, DC link selectable
z Protective function
Trip
Over Voltage, Under Voltage, Over Current, Over Current 2, Ground Fault current
detection, Inverter Overheat, Motor Overheat, Output Phase Open, Overload
Protection, Communication Error, Loss of Speed Command, Hardware Fault, Fan trip,
Brake error.
Alarm Stall prevention, overload
Momentary
Power
Loss
1)
Below 15 msec: Continuous operation (should be within rated input voltage, rated
output power.)
Above 15 msec: Auto restart enable
1) Single Phase products: Continuous operation (should be within rated input voltage, rated output
power)
z Environment
Protection
degree
IP 20, UL TYPE1
Ambient temp
-10°C ~ 50°C
Storage temp
-20°C ~ 65°C
Humidity Below 90% RH (no condensation)
Altitude/Vibration Below 1,000m, 5.9m/sec
2
(0.6G)
Atmospheric
pressure
70~106 kPa
Location Protected from corrosive gas, combustible gas, oil mist or dust

LSIS SV-iG5A Series Specifications

General

Brand	LSIS
Model	SV-iG5A Series
Category	Inverter
Language	English
