LSIS SV-iG5A Series User Manual

5-12
z Function group 2
LED
display
Address
for
communi
cation
Parameter
name
Min/Max
range
Description
Factory
defaults
Adj.
during run
Page
H27 A31B [Auto Restart
time]
0~60 [sec] This parameter sets the time
between restart tries.
1.0 O 8-20
H30 A31E [Motor type
select]
0.2~ 22.0 0.2 0.2kW
7.5
1)
X 8-16
~ ~
22.0 22.0kW
H31 A31F [Number of
motor poles]
2 ~ 12 This setting is displayed via rPM
in drive group.
4 X
H32 A320 [Rated slip
frequency]
0 ~ 10
[Hz]
⎟
⎠
⎞
⎜
⎝
⎛
×
−=
120
Prpm
ff
rs
Where,
s
f
= Rated slip frequency
r
f
= Rated frequency
rpm
= Motor nameplate
RPM
P
= Number of Motor
poles
2.33
2)
X
H33 A321 [Motor rated
current]
0.5~150
[A]
Enter motor rated current on the
nameplate.
26.3
X
H34 A322 [No Load
Motor Current]
0.1~ 50 [A] Enter the current value detected
when the motor is rotating in rated
rpm after the load connected to
the motor shaft is removed.
Enter the 50% of the rated current
value when it is difficult to
measure H34 – [No Load Motor
Current].
11
X
H36 A324 [Motor
efficiency]
50~100
[%]
Enter the motor efficiency (see
motor nameplate).
87
X
H37 A325 [Load inertia
rate]
0 ~ 2 Select one of the following
according to motor inertia.
0 X 8-1
0 Less than 10 times
1 About 10 times
2 More than 10 times
1)
: H30 is preset based on inverter rating.
2)
: H32 ~ H36 factory default values are set based on OTIS-LG motor.
