LSIS SV-iG5A Series User Manual

5-15
z Function group 2
LED
display
Address
for
communi
cation
Parameter
name
Min/Max
range
Description
Factory
defaults
Adj.
during
run
Page
H55
A337 [PID
output
frequency
high limit]
0.1 ~
400
[Hz]
This parameter limits the amount of the
output frequency through the PID control.
The value is settable within the range of
F21 – [Max frequency] and F23 – [Start
frequency].
60.00
O
8-10
H56
A338 [PID
output
frequency
low limit]
0.1 ~
400
[Hz]
0.50
O
H57
A339 [PID
standard
value
select]
0~4 Selects PID standard value.
Standard value is indicated in “rEF” of
Drive group.
0
X
8-10
0 Loader digital setting 1
1 Loader digital setting 2
2 V1 terminal setting 2: 0~10V
3 I terminal setting: 0~20mA
4 Setting as a RS-485
communication
H58
A33A PID
control
unit select
0~1 Selects a unit of the standard value or
feedback amount.
0
X
0 Frequency[Hz]
1 Percentage[%]
H60 A33C [Self-
diagnostic
select]
0 ~ 3 0 Self-diagnostic disabled 0 X 8-22
1 IGBT fault/Ground fault
2 Output phase short & open/
Ground fault
3 Ground fault (This setting is
unable when more than 11kW)
H61
1)
A33D [Sleep
delay
time]
0~2000[
s]
Sets a sleep delay time in PID drive. 60.0
X
8-13
H62 A33E [Sleep
frequency]
0~400[H
z]
Sets a sleep frequency when executing a
sleep function in PID control drive.
You can’t set more than Max.
frequency(F21)
0.00
O
H63 A33F [Wake up
level]
0~100[
%]
Sets a wake up level in PID control drive. 35.0
O
H64 A340 [KEB drive
select]
0~1 Sets KEB drive. 0
X
8-28
H65 A341 [KEB
action
start level]
110~140
[%]
Sets KEB action start level according to
level.
125.0
X
H66 A342 [KEB
action
stop level]
110~145
[%]
Sets KEB action stop level according to
level.
130.0
X
1):
Set H49 as a 1
2):
it is indicated when setting H64(KEB drive select) as a 1
(KEB does not operate when cut power after loading ting input (about 10%).
H67 A343 [KEB
action
gain]
1~2000
0
Sets KEB action gain. 1000
X
8-28
