LSIS SV-iG5A Series User Manual

5-16
LED
display
Address
for
communi
cation
Parameter
name
Min/Max
range
Description
Factory
defaults
Adj.
during
run
Page
H70 A346 [Frequenc
y
Reference
for
Accel/Dec
el]
0 ~ 1 0 Based on Max freq (F21) 0 X 7-12
1 Based on Delta freq.
H71 A347 [Accel/De
cel time
scale]
0 ~ 2 0 Settable unit: 0.01 second. 1 O 7-13
1 Settable unit: 0.1 second.
2 Settable unit: 1 second.
H72 A348 [Power on
display]
0 ~ 15 This parameter selects the parameter to
be displayed on the keypad when the
input power is first applied.
0 O 9-2
0 Frequency command
1 Accel time
2 Decel time
3 Drive mode
4 Frequency mode
5 Multi-Step frequency 1
6 Multi-Step frequency 2
7 Multi-Step frequency 3
8 Output current
9 Motor rpm
10 Inverter DC link voltage
11 User display select (H73)
12 Fault display
13 Direction of motor rotation
select
14 Output current 2
15 Motor rpm 2
16 Inverter DC link voltage 2
17 User display select 2
H73 A349 [Monitorin
g item
select]
0 ~ 2 One of the following can be monitored
via vOL - [User display select].
0 O 9-2
0 Output voltage [V]
1 Output power [kW]
2
Torque [kgf
⋅
m]
H74 A34A [Gain for
Motor rpm
display]
1 ~
1000
[%]
This parameter is used to change the
motor rotating speed (r/min) to
mechanical speed (m/mi) and display it.
100 O 9-1
H75 A34B [DB
resistor
operating
rate limit
select]
0 ~ 1 0 Unlimited 1 O 10-8
1 Use DB resistor for the H76 set
time.
H76 A34C [DB
resistor
operating
rate]
0 ~
30[%]
Set the percent of DB resistor operating
rate to be activated during one sequence
of operation.
10 O
