LSIS SV-iG5A Series User Manual

5-22
LED
display
Address
for
communic
ation
Parameter
name
Min/Max
range
Description
Factory
default
Adj.
during
run
Page
I42 A42A [Multi-
Accel time
5]
7.0
I43 A42B [Multi-
Decel
time 5]
7.0
I44 A42C [Multi-
Accel time
6]
8.0
I45 A42D [Multi-
Decel
time 6]
8.0
I46 A42E [Multi-
Accel time
7]
9.0
I47 A42F [Multi-
Decel
time 7]
9.0
I50 A432 [Analog
output
item
select]
0 ~ 3 Output
item
Output to 10[V] 0 O 9-6
200V 400V
0 Output
freq.
Max frequency
1 Output
current
150 %
2 Output
voltage
AC 282V AC 564V
3 Inverter
DC link
voltage
DC 400V DC 800V
I51 A433 [Analog
output
level
adjustmen
t]
10~200
[%]
Based on 10V. 100 O 9-6
I52 A434 [Frequenc
y
detection
level]
0 ~ 400
[Hz]
Used when I54 or I55 is set to 0-4.
Cannot be set higher than F21.
30.00
O
9-7
I53 A435 [Frequenc
y
detection
bandwidth
]
10.00
O
I54
A436 [Multi-
function
output
terminal
select]
0 ~ 19
0
FDT-1 12 O 9-8
1
FDT-2
2
FDT-3 9-9
3
FDT-4 17
I55 A437 [Multi-
function
relay
select]
4
FDT-5 9-10
5 Overload (OLt) 9-10
6 Inverter Overload (IOLt)
7 Motor stall (STALL)
8 Over voltage trip (Ovt)
