LSIS SV-iG5A Series User Manual

5-21
z Input/output group
LED
display
Address
for
communic
ation
Parameter
name
Min/Max
range
Description
Factory
default
Adj.
during
run
Page
I25 A419 [Input
terminal
status
display]
BIT
7
BIT
6
BIT
5
BIT
4
BIT
3
BIT
2
BIT
1
BIT
0
0 O 9-3
P8
P7
P6 P5
P4
P3 P2 P1
I26 A41A [Output
terminal
status
display]
BIT1 BIT0
0
O
9-3
3AC MO
I27 A41B [Filtering
time
constant
for Multi-
function
Input
terminal]
1 ~ 15 If the value is set higher, the
responsiveness of the Input terminal is
getting slower.
4
O
-
I30 A41E [Multi-
Step
frequency
4]
0 ~ 400
[Hz]
It cannot be set greater than F21 – [Max
frequency].
30.00
O
7-7
I31 A41F [Multi-
Step
frequency
5]
25.00
O
I32 A420 [Multi-
Step
frequency
6]
20.00
O
I33 A421 [Multi-
Step
frequency
7]
15.00
O
I34 A422 [Multi-
Accel time
1]
0~ 6000
[sec]
3.0 O 7-14
I35 A423 [Multi-
Decel
time 1]
3.0
I36 A424 [Multi-
Accel time
2]
4.0
I37 A425 [Multi-
Decel
time 2]
4.0
I38 A426 [Multi-
Accel time
3]
5.0
I39 A427 [Multi-
Decel
time 3]
5.0
I40 A428 [Multi-
Accel time
4]
6.0
I41 A429 [Multi-
Decel
time 4]
6.0
