XGB Analog edition manual
(2) Channel run/stop information
(a) It displays which channel is being used.
(3) Temperature value
It displays current temperature value. Its form is temperature value ×10.
— — — — — — — —
C
H
3
C
H
2
C
H
1
C
H
0
C
H
3
C
H
2
C
H
1
C
H
0
bit15 bit14 bit13 bit12 bit11 bit10 bit9 bit8 bit7 bit6 bit5 bit4 bit3 bit2 bit1 bit0
CH0 temperature conversion value
CH1 temperature conversion value
CH2 temperature conversion value
CH3 temperature conversion value
Run channel information
Bit
On (1): Run
Off (0): Stop
Disconnection information (bit)
Bit On (1): Disconnection
Bit Off (0): Normal
