Chapter 5 Thermocouple Input Module (XBF-TC04S,TC04B)
Memory
address
Description
Setting value R/W Instruction
Hex.
Dec.
scaling range
1B
H
27
Set error inf. Of CH0.
Setting error information (Flag) R GET
1C
H
28
Set error inf. Of CH1
1D
H
29
Set error inf. Of CH2
1E
H
30
Set error inf. Of CH3
1F
H
31
Cold junction
compensation temp. of
CH0.
Measured value of cold junction
compensation temp.
R GET
20
H
32
Cold junction
compensation temp. of
CH1.
21
H
33
Cold junction
compensation temp. of
CH2.
22
H
34
Cold junction
compensation temp. of
CH3.
23
H
~3F
H
35
~63
System area
(Offset gain storage area)
Read/Write unavailable unavailable -
Caution
(1) If input value of memory address 00
H
~1A
H
(0~26) is out of range of setting value,
U0x.01.8~U0x.01.B (setting error representation flag, in case of IEC type,
%UX0.x.24~%UX0.x.27) are on and it acts as default setting
value. Error information is displayed in 1B
H
~1F
H
(27~30) area.
(2)
System area (Offset gain storage area) is area where Read/Write is unavailable.
If this area changes, malfunction or breakdown may occur.
5 - 43
