5.8.3 Troubleshooting
(1) RUN LED flickers.
(2) RUN LED is off.
RUN LED f lickers .
RUN LED f lickers 0.2s intervals.
Contact the nearest agency or LS branch office.
Yes
RUN LED is off .
Thermocouple input module is installed correctly?
Correctly install this module.
Contact the nearest agency or LS branch office .
I/O information can be seen at the XG5000.
Normally operated if thermocouple input module with
error is changed to another module
No
Yes
No
Yes
Yes
Contact the nearest agency or LS branch office .
