Chapter 1 General
1 - 5
Item
XBF-AD08A
Analog input
range
Type
Voltage
Current
Range
DC 1 ~ 5V
DC 0 ~ 5V
DC 0 ~ 10V
(Input resistance: 1 MΩ min.)
DC 4 ~ 20㎃
DC 0 ~ 20㎃
(Input resistance: 250 Ω)
Input range can be voltage/current selector switch after being set
by user program or I/O parameter for each channel
Digital output
Type
12 bit binary data
Range
Unsigned
value
0 ~ 4000
Signed value
-2000 ~ 2000
Precise value
100 ~ 500 (DC 1 ~ 5V)
0 ~ 500 (DC 0 ~ 5V)
0 ~ 1000 (DC 0 ~ 10V)
400 ~ 2000 (DC 4 ~ 20㎃)
0 ~ 2000 (DC 0 ~ 20㎃)
Percentile
value
0 ~ 1000
Max. resolution
1/4000
1.25㎷ (DC 1~5V, 0~5V)
2.5㎷ (DC 0~10V)
5㎂ (DC4~20㎃, 0~20㎃)
Accuracy
± 0.5% or less
Max. conversion speed
1.5ms/channel
Absolute max. input
DC ±15V
DC +25㎃
No. of output channel
8 channels
Insulation method
Photo-coupler insulation between input terminal and PLC power
(No insulation between channels)
Connection Terminal
11 point terminal block
I/O points occupied
Fixed type: 64 points
Max. number of equipment
7 (when using XBM(C)-DxxxS type)
10 (when using XB(E)C-DxxxH type)
Additional
function
Filter function
Digital filter (4~64,000ms)
Average function
Time average (4~16,000ms)
Count average (2~64,000 times)
Moving average (2~100)
Alarm function
Disconnection detection (DC 1~5V, DC 4~20㎃)
Consumption
current
Inner (DC 5V)
105㎃
External (DC 24V)
85㎃
Weight
81g
