LSIS XBF-AH04A

XGB Analog edition manual
(4) Filter Constant Setting
(a) If set to 0, no filtration is processed.
(b) Default setting is 0 – no filtration process.
Bit15
Bit14 Bit13 Bit12 Bit11 Bit10 Bit9 Bit8 Bit7
Bit6 Bit5 Bit4 Bit3 Bit2 Bit1 Bit0
Input channel 0 filter constant (0 or 4 ~ 64000 ms)
Address3
Input channel 1 filter constant (0 or 4 ~ 64000 ms)
Address4
(5) Averaging Method Setting
(a) Averaging method can be one of; time average, cycle average, moving average.
(b) Default setting is no averaging throughout the channels.
Bit15 Bit14
Bit13
Bit12
Bit11
Bit10 Bit9 Bit8 Bit7 Bit6 Bit5 Bit4 Bit3 Bit2 Bit1 Bit0
Input CH.0
Address5
Set-up averaging method (4bit per Ch)
0 : Sampling
1 : Time average
2 : Cycle average
3 : Moving average
Input CH.1---- --
-
-
(6) Average Value Setting
(a) Set up average values in accordance with the setting area of the averaging method.
(b) If the average value is out of setting range, averaging is not applied.
비트15
비트14
비트13
비트12
비트11
비트10
비트9
비트8 비트7
비트6
비트5
비트4
비트3
비트2
비트1
비트0
Input channel 0 average value
Address6
Input channel 1 average value
Address7
Input channel# average value setting
Time average : 4 ~ 16000 [ms]
Cycle average : 2 ~ 64000 [Cycle]
Moving average : 2 ~ 100 [samples]
6 - 38
