7.13.3 Troubleshooting
(1) INPUT LED is off.
INPUT LED is off..
Analog input module is correctly
installed.
Install the module correctly
No
Yes
XG5000 software shows I/O information
Contact nearest dealer or A/S center
No
Yes
System resumes normal function if the
module is replaced.
Yes
Contact nearest dealer or A/S center
(2) LED flickering.
LED flikering
LED flikering 0.2s intervals.
Contact nearest dealer or A/S center
No
Yes
LED flikering 1s intervals
Input wire is correct.
Correct wiring according to user manual
(Check line open)
No
Yes
Parameter setting is normal
(Check with PUT command)
Operation parameter setting error
Correct the error according to user manual
(Check error code)
7 - 38
