Chapter 7 Analog Input Module (XBF-AD08A)
7.13 Troubleshooting
This section describes methods for identifying the troubles which may occur during the operation of
analog input module, and their solutions.
7.13.1 LED Indication for Error
An analog input module has one INPUT LED to indicate error status of the module.
Item Normal State
Channel Open
(Input)
Parameter Setting
Error
Module H/W
Failure
(Serious Failure)
LED On
Flikering
1s intervals
Flikering 1s intervals
(input parameter
setting error)
Flikering 0.2s
Intervals
Module
Behavior
All functions are
normal
All functions are
performed.
Indicates min. input
value
All functions work at
default parameter
setting
Module cannot
function
Action - Check input wire
Check parameter
setting
Request for A/S
7.13.2 Checking Module Condition
XG5000’s system monitor enables verification of the analog mix module conditions (module type,
module information, OS version).
(1) Procedure
The verification can be done in 2 ways;
(a) [Monitor] -> [System Monitor] -> mouse right click on module icon -> [Module Information]
(b) [Monitor] -> [System Monitor] -> double click module icon.
(2) Module Information
(a) Module type: shows the information on the present module.
(b) Module information: shows the OS version of the module.
(c) OS version: shows release date of Module OS.
