Chapter 9 Analog Output Option Board (XBO-DA02A)
9.2.2 Performance specifications
Here describes performance specification of analog output module.
Item Specification
No. of channels
2 channels
Analog
output
range
Type
Voltage
Current
Range
DC 0 ~ 10V
(Load resistance: 2
㏀ Min.)
DC 4 ~ 20
㎃
DC 0 ~ 20
㎃
(Load resistance: 450Ω Max.)
Output range can be set at user program or I/O parameter for each
channel
Digital
input
Type 12-bit binary data
Range
Unsigned
value
0~4000
Signed value -2000 ~ 2000
Precise value 0 ~ 1000 (DC0~10V)
400 ~ 2000 (DC4~20
㎃)
0 ~ 2000 (DC0~20
㎃
)
Percentile value 0 ~ 1000
Maximum resolution
1/4000 (DC 4 ~ 20㎃: 1/3200)
2.5㎷ (DC 0 ~ 10V)
5
㎂
(DC 0~20
㎃
)
6.25
㎂
(DC 4~20
㎃
)
Accuracy
±1.0% or less
Maximum conversion speed
1

/channel + scan time
Additional function
Channel output state setting (former, min, middle, max value)
Gain adjustment function
Insulation method
no insulation between analog output channels
no insulation between output terminal and PLC main unit
I/O terminal
5-point terminal block
Power supply
Internal 5V
I/O points occupied
Fixed type: 64 points
Supply power
Internal DC5V
Current consumption
150
㎃
Weight
20g
Note1) In order to use analog output option board, the following version is needed.
Main unit Version information
XBC E type
V1.1 or above
XBC S type
V1.1 or above
XBC SU type
V1.0 or above
XEC E type
V1.0 or above
XEC SU type
V1.0 or above
XG5000
V.3.61 or above
Note2) Offset/gain value on analog I/O range can be adjusted at XG5000 - I/O parameter
9 - 3
