Chapter 10 Analog I/O Option Board (XBO-AH02A)
10.2.2 Performance specifications
Performance specifications are as follows.
(1) Input performance specification
Items
Input performance specification
Number of channels
1 channel
Analog
input
range
Type
Voltage
Current
Range
DC 0 ~ 10V
(Input resistance: 1㏁ Min.)
DC 4 ~ 20㎃
DC 0 ~ 20㎃
(Input resistance: 250 Ω)
Set by external voltage/current wiring after being set at user program
or I/O parameter per each channel
Digital
output
Type
12 bit binary data
Range
Unsigned
value
0 ~ 4000
Signed value
-2000 ~ 2000
Precise
value
0 ~ 1000 (DC 0 ~ 10V)
400 ~ 2000 (DC 4 ~ 20
㎃
)
0 ~ 2000 (DC 0 ~ 20
㎃
)
Percentile
value
0 ~ 1000
Max. resolution
1/4000 (DC 4~20
㎃
: 1/3200)
2.5㎷ (DC 0~10V)
5
㎂
(DC 0~20
㎃
)
6.25
㎂
(DC 4~20
㎃
)
Accuracy
±1.0% or less
Max. conversion speed
1ms/channel + scan time
Absolute max. input
DC +12V / -10V
DC ±25
㎃
Additional
function
Average function
Count average (2 ~ 64,000 times)
Gain adjustment
function
Gain adjustment (-40~40)
10 - 3
