(2) Output performance specification
Items
Output performance specification
Number of channels
1 channel
Analog
output
range
Type
Voltage
Current
Range
DC 0 ~ 10V
(Load resistance: 2kΩ Min.)
DC 4 ~ 20
㎃
DC 0 ~ 20㎃
(Load resistance: 450 Ω Max.)
Set at user program or I/O parameter per each channel per each
channel
Digital
input
Type
12 bit binary data
Range
Unsigned
value
0 ~ 4000
Signed value
-2000 ~ 2000
Precise
value
0 ~ 1000 (DC 0 ~ 10V)
400 ~ 2000 (DC 4 ~ 20mA)
0 ~ 2000 (DC 0 ~ 20mA)
Percentile
value
0 ~ 1000
Max. resolution
1/4000 (DC 4 ~ 20
㎃
: 1/3200)
2.5㎷ (DC 0~10V)
5
㎂
(DC 0~20
㎃
)
6.25
㎂
(DC 4~20
㎃
)
Accuracy
±1.0% or less
Max. conversion speed
1ms/channel + scan time
Additional function
CH output status setting
(select among former, min, middle, max value)
Gain adjustment function
(3) I/O Common performance specification
Items
I/O common performance specification
Insulation method
Non-insulation betweens analog I/O channels
Non-insulation between I/O terminal and PLC main unit
I/O terminal
5-point terminal block
I/O occupation point
Fixed type: 64 points
Supply power
Internal DC5V
Consumption current
150
㎃
Weight
20g
Note1) In order to use analog I/O option board, the following version is needed.
Main unit Version information
XBC E type
V1.1 or above
XBC S type
V1.1 or above
XBC SU type
V1.0 or above
XEC E type
V1.0 or above
XEC SU type
V1.0 or above
XG5000
V.3.61
Note2) Offset/gain value on the analog output range can be adjusted at XG5000- I/O parameter
