LSIS XBF-AH04A

XGB Analog edition manual
10.11.2 Operation Parameter Setting Area
The operation parameter setting area of the analog mix module is as follows.
Memory
Add.
Description Setting R/W Command
0 Enable channel Bit Off (0): disable, Bit ON (1): enable R/W
PUT/GET
1 I/O range setting
Input range setting (4 bit per channels)
0: 4 ~ 20 
1: 0 ~ 20 
2: 0 ~ 10 V
R/W
2 I/O data type setting
I/O data type setting
(4 bit per channels)
0: 0 ~ 4000
1: -2000 ~ 2000
2: Precise value
3: 0 ~ 1000
- In case of precise value
4 ~ 20 : 400 ~ 2000
0 ~ 20 : 0 ~ 2000
0 ~ 10 V: 0 ~ 1000
R/W
3
Input channel 0 count
average value setting
0 or 2 ~ 64000 [times] R/W
8 CH output state setting
CH output state setting (4bit per channel)
0: Former value
1: min value
2: middle value
3: max value
R/W
9
Input channel 0 gain
weighting
-40~40
R/W
11
Output channel 0 gain
weighting
R/W
13 Setup error information
100: input ch range setting error
200: input ch data type setting error
300: input ch average value setting error
400: input ch gain weighting setting error
500: output ch range setting error
600: output ch data type setting error
700: output ch output state setting error
800: output ch gain weighting setting error
900: output ch input value excess error
R GET
10 - 34
