Chapter 10 Analog I/O Option Board (XBO-AH02A)
(6) Setup error information output area (address 13)
(a) Saves error code detected when setting (setting by program)
(b) Setting error is canceled when value is reset to make it in the valid range
(c) When U0X.01.8~ U0X.01.A (setting error flat) is on, check that area and fix the corresponding
setting to cancel the error
(d) When using GET instruction, address is as follows
bit15 bit14 bit13 bit12 bit11 bit10 bit9 bit8 bit7 bit6 bit5 bit4 bit3 bit2 bit1 bit0
Setting error information
13
Type
Error
code
Description Priority Remark
Input
error
100 Input CH range setting error 2
−
200 Input CH data type setting error 3
300 Input CH count average value setting error 4
400 Input CH gain weighting setting error 5
Output
error
500 Output CH range setting error 6
600 Output CH data type setting error 7
700 Output CH state setting error 8
800 Output CH gain weighting setting error 9
900 Output CH input value excess error 1
(e) When more than two errors occur simultaneously, it saves error code having higher priority.
10 - 41
