XGB Analog edition manual
(4) Disconnection information (address 6)
(a) Displays disconnection information of channel.
(b) In case of using GET instruction, Disconnection Information address is as follows.
bit15
bit14
bit13
bit12
bit11
bit10
bit9
bit8
bit7
bit6
bit5
bit4
bit3
bit2
bit1
bit0
CH0 disconnection information (0: normal, 1: disconnection)
Address6
(5) Count average value setting (address 14)
(a) Count average value should be 0 or 2~64000.
(b) If count average value is set as 0, averaging process is not applied and sampling-processed
temperature value is outputted.
(c) When count average value is larger than 64001, 0 (Averaging disabled) is selected by force
(d) In case of using PUT instruction, Count Average Value Setting address is as follows.
bit15
bit14
bit13
bit12
bit11
bit10
bit9 bit8 bit7 bit6 bit5 bit4
bit3
bit2
bit1
bit0
CH0 count average setting: 0 or 2~64,000
Address14
(6) Error information (address 15)
(a) Saves error code detected at setup (in case of setup by the program)
(b) Setting error is canceled when invalid setting is corrected by resetting
(c) In case of GET instruction, setting error information address is as follows.
bit15 bit14
bit13
bit12 bit11 bit10
bit9 bit8 bit7 bit6 bit5 bit4 bit3 bit2 bit1
bit0
CH0 setup error information
Address15
Type
Error
code
Description Priority Remark
Setup
error
Input sensor type setting error
-
Input count average value rage setting error
11 - 24
