LSIS XBF-AH04A

Chapter 12 Thermocouple Input Option Module (XBO-TC02A)
12.12.3 Operation parameter setting area
It describes operation parameter setting area of thermocouple input module.
Memory
address
Description
Setting value R/W Instruction
Hex.
Dec.
00
H
0
Designate a channel to
use
bit0: bit3, 0: stop, 1: run R/W
PUT/GET
01
H
1
Set sensor type of CH 0
K:0, J:1 R/W
02
H
2
Set sensor type of CH 1
05
H
5
Designate temperature
metric system
bit0: bit3, 0: Celsius, 1:
Fahrenheit
R/W
0E
H
14
CH0 average value
Count average: 2~64000 times R/W
0F
H
15
CH1 average value
10
H
16 Error information
10#: sensor type setting error
20#: count average value
setting error
R GET
11
H
17
Cold junction
compensation temp.
Measured value of cold junction
compensation temp.
R GET
12
H
~18
H
18
~24
System area
(Offset gain storage area)
Read/Write unavailable unavailable -
Remark
Warning (1) System area (Offset gain storage area) is area where Read/Write is unavailable.
If this area changes, malfunction or breakdown may occur.
12 - 27
