XGB Analog edition manual
(6) Max/Min Value Monitor
Max/Min value of input channel in operation can be monitored. However, visible Max/Min
values are based on present value.
So Max/Min value is not saved when [Monitoring/Test Screen] is closed.
[Max/Min Value Monitor] execution screen
(7) Close
[Close]: [Close] is used to escape from the monitoring/test screen. When the monitoring
/test screen is closed, the max. value, the min. value and the present value will not be
saved any more.
Monitoring of Max/Min value
13 - 28
