2 - 32
(3) Setting output data type
(a) The range of digital output data for analog input can be specified for respective channels.
(b) If the output data range is not specified, the range of all the channels will be set to 0 ~ 4000.
(4) Setting filter process
If the filter process is not specified, the filter process of all channels will not be executed.
(5) Setting filter constant
When using the filter process, specify the filter constant.
(6) Setting average process
If the average process is not specified, the average process of all channels will not be executed.
bit15 bit14 bit13 bit12 bit11 bit10 bit9 bit8 bit7 bit6 bit5 bit4 bit3 bit2 bit1 bit0
— — — — ———— CH.3 CH.2 CH.1 CH.0
bit15 bit14 bit13 bit12 bit11 bit10 bit9 bit8 bit7 bit6 bit5 bit4 bit3 bit2 bit1 bit0
— — — — ————————
CH.
3
CH.
2
CH.
1
CH.
0
bit15 bit14 bit13 bit12 bit11 bit10 bit9 bit8 bit7 bit6 bit5 bit4 bit3 bit2 bit1 bit0
CH.0 filter constant
CH.1 filter constant
CH.2 filter constant
CH.3 filter constant
bit15 bit14 bit13 bit12 bit11 bit10 bit9 bit8 bit7 bit6 bit5 bit4 bit3 bit2 bit1 it0
— — — — ————————
CH.
3
CH.
2
CH.
1
CH.
0
Setting output data type (bit)
 00: 0 ~ 4000
 01: -2000 ~ 2000
 10: 0 ~ 1000(400 ~ 2000/0 ~ 2000)
 11: 0 ~ 1000
Address 2
Setting filter process (bit)
Bit On (1): used, bit Off (0): not used
Address 3
Address 4
Address 5
Address 6
Address 7
Setting average process (bit)
Bit On (1): used, Bit Off (0): not used
Address 12
