Chapter 2 Analog Input Module (XBF-AD04A)
2 - 33
(7) Setting average process method
This area is used to specify average processing method, where ‘count average’ and ‘time
average’ are available.
(8) Error code (address 22)
(a) It saves the error code detected from A/D conversion module.
(b) Error type and details is as below.
Error code (Dec.) Details Remark
0 Normal operation RUN LED flickering
50# Exceeding of filter constant setting range
Flickering RUN LED
1s intervals
60# Exceeding of time average setting range
70#
Exceeding of Frequency average setting
range
80# Setting error of analog input range
※ # of the error codes stands for the channel with error found.
(c) If 2 or more errors occur, the module sill not save other error codes than the first error code
found.
(d) If an error found is corrected, use the ‘flag to request error clear’, or let power OFF
ON in
order to stop LED blinking and to delete the error code.
.
bit15 bit14 bit13 bit12 bit11 bit10 bit9 bit8 bit7 bit6 bit5 bit4 bit3 bit2 bit1 bit0
— — — — ———— CH.3 CH.2 CH.1 CH.0
bit15 bit14 bit13 bit12 bit11 bit10 bit9 bit8 bit7 bit6 bit5 bit4 bit3 bit2 bit1 bit0
— — — — ————
Error code
Address 22
Setting average process method (bit)
00: count average
01: time average
Address 13
