12 - 4 Troubleshooting Preparations Issue 5 June 2000
Troubleshooting Procedure, continued
Troubleshooting
Tables
4. Based on the information presented by the alarm LEDs, select the
appropriate table from the lists below:
Identifying
Problems
5. Once the appropriate table is identified, use the status LEDs and the
alarm menu data to identify the specific problem that is causing the
alarm.
Section 13, Troubleshooting Millennium Systems
Alarm LED Table
AC 13-A, AC Alarms
BATT 13-B, Battery Alarms
BD 13-F, Miscellaneous Alarms
CTRL 13-C, Controller Alarms
DIST 13-D, Distribution Alarms
RECT 13-E, Rectifier Related Alarms
No LED* 13-F, Miscellaneous Alarms
*If an alarm condition exists, but no alarm LED is lit,
refer to Table 13-F.
Section 14, Troubleshooting Vector Systems
Alarm LED Table
AC 14-A, AC Alarms
BATT 14-B, Battery Alarms
BD 14-F, Miscellaneous Alarms
CTRL 14-C, Controller Alarms
DIST 14-D, Distribution Alarms
RECT 14-E, Rectifier Related Alarms
No LED* 14-F, Miscellaneous Alarms
*If an alarm condition exists, but no alarm LED is lit,
refer to Table 14-F.
