Lucent Technologies Galaxy Power System 4812
2 - 4 System Description Issue 5 June 2000
Figure 2-2: Schematic of Half Height Cabinet
Control
and
Monitor
AC
Battery String(s)
Mounted Below
Half Height Cabinet
To Loads
AC
Ground
Cabinet
Ground
System (CO)
Ground
Battery
Shunt
