Lucent Technologies Galaxy Power System 4812
5 - 2 AC Input Panels Issue 5 June 2000
Overview, continued
Cross Reference of
Cabinets and
Panels
Table 5-A identifies which cabinet uses each of the panels.
Illustrations Circuit breaker panels are shown in Figures 5-1 and 5-2; terminal strip
panels are shown in Figures 5-3 and 5-4.
Table 5-A: AC Input Panels
Panel Cabinet Figure
H569-436 G73F
(ED83142-30 G6)
Full-height cabinet with two shelves of rectifiers that
are connected phase to phase
Figure 5-1
H569-436 G71H
(ED83142-30 G6)
Half-height cabinet with two shelves of rectifiers that
are connected phase to phase
Figure 5-1
H569-436 G74F
(ED83142-30 G6M)
Full-height cabinet with two shelves of rectifiers that
are connected phase to neutral
Figure 5-1
H569-436 G74H
(ED83142-30 G6M)
Half-height cabinet with two shelves of rectifiers that
are connected phase to neutral
Figure 5-1
H569-436 G72F
(ED83142-30 G7)
Full-height cabinet with three shelves of rectifiers
that are connected phase to phase
Figure 5-2
H569-436 G79F
(ED83142-30 G8)
Full-height cabinet with two shelves of rectifiers that
are connected phase to phase or phase to neutral
Figure 5-3
H569-436 G76H
(ED83142-30 G8)
Half-height cabinet with two shelves of rectifiers that
are connected phase to phase or phase to neutral
Figure 5-3
H569-436 G77F
(ED83142-30 G9)
Full-height cabinet with three shelves of rectifiers
that are connected phase to phase or phase to neutral
Figure 5-4
H569-436 G78F
(ED83142-30 G9)
Full-height cabinet with four shelves of rectifiers that
are connected phase to phase or phase to neutral
Figure 5-4
