Lucent Technologies Galaxy Power System 4812

6 - 2 Battery Connection Panels Issue 5 June 2000

Figure 6-1: H569-436 G30 (ED83143-30 G32)

Battery Connection Panel

Two 500A Contactors

Contactor Control Cards

Two 1000A Shunts

Connects to

Charge Return Bus

9" REF

(229mm)

Figure 6-2: H569-436 G31 (ED83143-30 G31)

Battery Connection Panel

Contactor Control Card

1200A Contactor

1500A Shunt

Connects to

Charge Return Bu

6" REF

(152mm)
