Issue 5 June 2000 Troubleshooting Preparations 12 - 11
Reference Figures, continued
AC Input
Figure 12-8: Detail of AC Input Panel and Rectifier Shelf
4
8
12
1
5
9
2
6
10
3
7
11
112
AC Circuit Breakers for
Rectifiers
through
123456789101112
AC Input
Rectifier
596
AC Input Voltage Range
176Vac - 264Vac
DC Output
Serial Bus Connection
to Controller
Rectifier Positions
Rectifier or Converter Position
Rectifier Shelf
