9 - 6 Specifications Issue 5 June 2000
Battery Connection Panels
Table 9-D: Battery Connection Panels
Description
H569-436
Group No.
ED83143-30
Group No.
LVBD: (2) 500A contactors with
1000A shunts
G30 G32
LVBD: 1200A contactor with 1500A
shunt
G31 G31
(2) fuse holders for 315-630A NH3
DIN fuses with 600A shunts
G34 G41
Fuse holder for 315-630A NH3 DIN
fuse with 600A shunt
G35 G42
LVBD: 800A contactor with 600A
shunt
G36H G33
Off-Line Equalize (OLE)
with (3) 600A fuse holders (US style),
(3) 1000A shunts, and (1) 1200A
contactor
G37F G60
Off-Line Equalize (OLE)
with (3) 600A fuse holders (US style)
and (3) 1000A shunts
G38F G61
LVBD: 1200A contactor, (2) NH3
DIN fuses and (2) 600A shunts
G80
G31 and
(1) G43
LVBD: 1200A contactor, (4) NH3
DIN fuses and (4) 600A shunts
G81
G31 and
(2) G43
LVBD: 1200A contactor, (6) NH3
DIN fuses and (6) 600A shunts
G82
G31 and
(3) G43
600A shunt
G84H G34
1000A shunt
G85F G35
