Lucent Technologies Galaxy Power System 4812
7 - 6 DC Distribution Panels Issue 5 June 2000
Figure 7-9: H569-436 G60 (ED83143-30 G20/26)
DC Distribution Panel
Alarm Cards
14 Positions for
DIN Circuit Breakers
Connects to
Charge Return Bus
6" REF
(152mm)
Figure 7-10: H569-436 G61 (ED83143-30 G25/29)
DC Distribution Panel
Alarm Cards
10 Positions for
DIN Circuit Breakers
Connects to
Charge Return Bus
6" REF
(152mm)
