Lucent Technologies Galaxy Power System 4812
Issue 5 June 2000 Rectifiers 4 - 3
Front Panel Display, continued
Illustration Figure 4-1 shows the rectifier’s front panel.
Figure 4-1: Rectifier Front Panel
ID
ALM
ON
STBY
LIM FAN
ALM
BST
