Lucent Technologies Galaxy Power System 4812
Issue 5 June 2000 Specifications 9 - 3
Rectifier
Table 9-B: 596A Rectifier Specifications
Electrical
Input
Voltage Range 176-264Vac, 2-wire, single phase
Frequency Range 47 - 63 Hz
Power Factor > 0.98 for loads > 50%
High Voltage Shutdown
Internal Selective High Voltage
Shutdown (ISHVSD)
Backup High Voltage Shutdown
(BUHVSD)
596A Float 56.0Vdc Nom.
1,
2
596A Boost 56.0Vdc Nom.
1,
2
596A Equalize 56.0Vdc Nom.
1,
2
596A Float/Boost 59.52Vdc
3
596A Equalize 66.0Vdc
3
1
Selectable/programmable through Galaxy Controller
2
Factory default settings – actual range is 44 - 60Vdc
3
Factory default settings – Float/Boost range is 58.51 - 60.53Vdc,
Equalize range is 65.2 - 67.0Vdc
Rated Service Entrance Surge Protector: It is important that the service entrance
surge protector (if provided) be coordinated with the internal surge protection and
that it clamps at a lower voltage then the internal protection. The internal protection
of the 596A has the following voltage and current characteristics:
Phase to Phase Voltage MOV Conduction Current
320Vac (RMS) 0A
620V maximum clamping 1mA (DC test current)
810Vpeak 100A peak (8 x 20µs)
Output
Output Current 50 amperes
Float/Boost Voltage 44-58Vdc
Total Harmonic Distortion 10% at Nom. Line V
Regulation ±0.5%
Ripple 100 mVrms
Noise < 2mV psophometric
Permanent Overload 55A dc maximum
Current Limit Set Point 15A-55A
Note: When using the maximum 16
rectifiers in a cabinet, do not exceed 50
amperes current limit per rectifier at 65°C.
