Lucent Technologies Galaxy Power System 4812
9 - 4 Specifications Issue 5 June 2000
Mechanical
Width 5.25 in. (133.35 mm)
Height 8 in. (203.2 mm)
Depth 19.75 in. (501.65 mm)
Weight 20 lbs. (9 kg)
Environmental
Efficiency > 90% typical
Operating Temperature -40°C to +65°C
Operating Relative Humidity 5% to 90%
Heat Release
52Vdc, 40A
52Vdc, 50A
Per rectifier:
231W [788.9 BTU/hr]
288W [983 BTU/hr]
Short Term Operating Relative
Humidity
5% to 90%
Storage Temperature -45°C to 85°C
Storage Relative Humidity 5% to 90%
Altitude -50 to 4000 meters
Note: For altitudes above 1500 meters, derate
the temperature by 0.656° Celsius per 100
meters.
Audible Noise < 52dBA
EMC EN 50022, level B, conducted and radiated
(CISPR 22)
Standards Compliance
Safety Standard EN 60950 (IEC950)
Certification Marks UL, VDE, CE
Rectifiers are individually UL Recognized
and/or CSA Certified to UL1950 and CSA
C22.2 No 234/950. Rectifiers are also
approved to IEC-950/EN60950 by an EC
Notified Body and have outputs classified as
SELV.
Table 9-B: 596A Rectifier Specifications
