Lucent Technologies Galaxy Power System 4812
Issue 5 June 2000 System Description 2 - 5
Figure 2-3: Schematic of Full Height Cabinet
AC
Ground
Cabinet
Ground
System (CO)
Ground
Control
and
Monitor
Battery
String
To Loads
Battery
Shunt
AC
