Lucent Technologies Galaxy Power System 4812 - Figure 7-11: H569-436 G65 (ED83143-30 G24;28) DC Distribution Panel; Figure 7-12: H569-436 G66 (ED83143-30 G23;27) DC Distribution Panel

Lucent Technologies Galaxy Power System 4812
Issue 5 June 2000 DC Distribution Panels 7 - 7
Figure 7-11: H569-436 G65 (ED83143-30 G24/28)
DC Distribution Panel
Alarm Cards
14 DIN Fuse Holders
Connects to
Charge Return Bus
6" REF
(152mm)
Figure 7-12: H569-436 G66 (ED83143-30 G23/27)
DC Distribution Panel
Alarm Cards
10 DIN Fuse Holders
Connects to
Charge Return Bus
6" REF
(152mm)
