Lucent Technologies Galaxy Power System 4812

6 - 4 Battery Connection Panels Issue 5 June 2000

Figure 6-5: H569-436 G36H (ED83143-30 G33)

Battery Connection Panel

600A Shunt

800A Contactor

Contactor Control Card

Figure 6-6: H569-436 G37F/38F (ED83143-30 G60/61)

Battery (OLE) Connection Panel

Alarm/Terminal Card

(3) 600A Fuses

(3) 1000A Shunts

(1) 1200A Contactor

(G60 only)

Connects to

Charge Return Bus

15" REF

(381mm)

Note: For more information, refer

to the OLE Product Manual,

Select Code 167-792-200
