Lucent Technologies Galaxy Power System 4812
9 - 2 Specifications Issue 5 June 2000
Units Per Initial Cabinet
Full Height Half Height
Rectifiers 1 - 12 or 1 - 16 1 - 8
Controller
1
Battery Disconnect
Modules
0 - 1
DC Distribution 1 - 6 1 - 3
Units Per Supplemental Cabinet
Rectifiers 1 - 12 or 1 - 8 N/A
Battery Disconnect
Modules
0 - 1 N/A
DC Distribution 1 - 6 N/A
Environmental
Operating Ambient
Temperature
0°C to 45°C
Altitude -50 to 4000 meters
Note: For altitudes between 1500 and 4000 meters, derate the
maximum temperature by 0.656°C per 100 meters.
Humidity 5% to 90% non-condensing
Radiated and
Conducted
Emissions
EN50082-1, EN50082-2, EN50081, EN61000
Electromagnetic
Immunity
Level B
Earthquake Rating Zone 4, upper floors
Standards Compliance
Agency Approvals CE Marked, UL
Underwriters Laboratories (UL) Listed per Subject Letter 1801,
DC Power Distribution Centers for Telecommunications
Equipment
Table 9-A: Galaxy Power System 4812 Specifications
