Issue 3 July 1998 Product Description 2 - 21
the RIB and the rectifier adapter board (RAB). See “Rectifier
Adapter Board (RAB)” in this section.
Controller
Specifications
Table 2-A: ECS-12U Controller Electrical Specifications
Float Voltage
47.0 - 58.5 volts dc (48 volts dc nominal)
23.5 - 29.0 volts dc (24 volts dc nominal)
Operating Voltage
40.0 - 60.0 volts dc (48 volts dc nominal)
20.0 - 30.0 volts dc (24 volts dc nominal)
Input Power 8 - 16 watts, depending on options provided
Display Meter
4-digit backlit LCD
Range:
0.00 to +/-60.00 V (voltmeter)
0.0 to 8000.0 A(ammeter)
Accuracy:
+/-0.5% of full scale reading (ammeter)
+/-0.05% of full scale reading (voltmeter)
Resolution:
+/-0.1 ampere < 1000 amperes
+/- 1 ampere for ≥ 1000 amperes
Plant Shunt
50 millivolts at 300, 600, 1200, 2000, 2600,
4000, 6000 or 8000 amperes
Alarm Contact
Rating
60 volts dc, 1.0 ampere, Form C
Temperature
32 to 122° F
(0 to 50°C)
Altitude
-200 to 13,000 feet (-61 to 3962 meters)
For altitudes of 5000 to 13,000 feet, derate
maximum temperature by 3.6° F per 1000
feet above 5000 feet.
For altitudes of 1524 to 3962 meters, derate
maximum temperature by 0.656° C per 100
meters above 1524 meters.
Humidity 10% to 95% noncondensing
Electrostatic
Discharge
IEC 801-2 Level 5 (15kV) at 40% relative
humidity
Radiated and
Conducted
Emissions
FCC Level A
Electromagnetic
Immunity
10 V/m over the range of 20 to 2000 MHz
