Lucent Technologies Lineage
®
2000 ECS-12U Controller J85501E-2
Issue 3 July 1998 Installation and Setup 4 - 27
Table 4-H: AKC1B Shunt Isolator Circuit Pack
Shunt Current Programming Table
Shunt
Current
Rating
(Amps)
AKC1B, SW2
ECS CP1,
SW109
ECS
CP2,
SW202
12345678910123456234
50 1111111001100011101
75 1010000001100011101
100 1000000001100011101
150 0100000001100011101
200 0010000001100011101
250 0001111101100011101
300 0001111001100011101
400 0000111001100011101
500 0000001001100011101
600 0000000001100011101
800 0010000001010000110
1000 0001111101010000110
1200 0001111001010000110
1300 0100000001000100100
1500 0000001101010000110
2000 0000001001010000110
2400 0000000001010000110
2600 0001111001000100100
3000 0000011001001011010
4000 0000000001001011010
5000 0000001101001000000
5200 0000000001000100100
6000 0000011001001000000
8000 0000000001001000000
10000* 0000001101000000111
15000* 0000001000000000111
*Actual load should not exceed 8000 amperes.
