Lucent Technologies Lineage 2000 ECS-12U User Manual

Lucent Technologies Lineage
®
2000 ECS-12U Controller J85501E-2
Issue 3 July 1998 Ordering 3 - 3
Rectifier
Interface
Cables
Table 3-B: Available Rectifier Interface Cables
Cable Description Cable Assembly
Control cable required to connect one Lucent
Technologies switchmode rectifier shelf with
one, two, or three switch mode rectifiers
H285-226, L42
Control cable required to connect one Lucent
Technologies 24-volt Lineage
®
single phase
ferroresonant rectifier (J85502 series)
H285-226, L43
Control cable required to connect one Lucent
Technologies 48-volt Lineage
®
single phase
ferroresonant rectifier (J85502 series)
H285-226, L44
Control cable required to connect one
non-Lucent Technologies rectifier or one
Lucent Technologies rectifier not listed on
this table.
H285-226, L45
Control cable required to connect one Lucent
Technologies rectifier J87434 or J87435
equipped with SP3
H285-226, L46
Control cable required to connect one Lucent
Technologies rectifier J87434 equipped with
SP8, or J87436 or J87438 equipped with SP7
(24 volt only)
H285-226, L47
Control cable required to connect one Lucent
Technologies rectifier J87435 equipped with
SP8, or J87437 or J87439 equipped with SP7
(48 volt only)
H285-226, L48
Control cable required to connect one Lucent
Technologies rectifier J87436 or J87438
equipped with SP1 (24 volt only)
H285-226, L49
Control cable required to connect one Lucent
Technologies rectifier J87437 or J87439
equipped with SP1 (48 volt only)
H285-226, L50
