Lucent Technologies Lineage
®
2000 ECS-12U Controller J85501E-2
4 - 26 Installation and Setup Issue 3 July 1998
Plant Alarms Connect major and minor alarms for the battery plant to terminal
block TB501 on the FAB mounted on the controller door.
Connect major alarms to either pins 2 or 4 on TB501. Connect
minor alarms to either pins 3 or 5 on TB501. See Table 4-E for
terminal block pin assignments. The terminal block accepts 22-
to 24-gauge stranded wire. Strip wire ends and clamp directly to
the terminal block. Alarm inputs to TB501-2 to TB501-5 must
be current-limited by an external 1KΩ, 2W resistor.
TB104-4 PMJEC Power Major External, alarm causes closure
TB104-5 PMJER Power Major External, return
TB104-6 PMJEO Power Major External, alarm causes open
TB104-7 PMJVC Power Major Visual, alarm causes closure
TB104-8 PMJVR Power Major Visual, return
TB104-9 PMJVO Power Major Visual, alarm causes open
TB104-10 MJFEC
Fuse Alarm Major, External, alarm causes
closure
TB104-11 MJFER Fuse Alarm Major, External, return
TB104-12 MJFEO
Fuse Alarm Major, External, alarm causes
open
Table 4-F: CP1 Terminal Block Pin Assignments
for 113B Control Unit
Pin
Number
Designation Definition
Table 4-G: Shunt Isolator Circuit Pack
Shunt Voltage Programming Table
Shunt
Voltage
Rating
AKC1B, SW1
123
25mV 1 1 1
50mV 1 1 0
100mV 1 0 0
150mV 0 0 0
