TB102-3 BDEO
Battery on Discharge External, alarm causes
open
TB102-4 HVEC High Voltage External, alarm causes closure
TB102-5 HVER High Voltage External, return
TB102-6 HVEO High Voltage External, alarm causes open
TB102-7 ACFEC AC Fail External, Alarm causes closure
TB102-8 ACFER AC Fail External, return
TB102-9 ACFEO AC Fail External, alarm causes open
TB102-10 LVC Low Voltage Contactor, alarm causes closure
TB102-11 LV Low Voltage Contactor, alarm return
TB102-12 LVO Low Voltage Contactor, alarm causes open
TB103-1 PMNAC Power Minor Audible, alarm causes closure
TB103-2 PMNAR Power Minor Audible, return
TB103-3 PMNAO Power Minor Audible, alarm causes
TB103-4 PMNEC Power Minor External, alarm causes closure
TB103-5 PMNER Power Minor External, return
TB103-6 PMNEO Power Minor External, alarm causes open
TB103-7 MNFEC
Fuse Alarm Minor, External, alarm causes
closure
TB103-8 MNFER Fuse Alarm Minor, External, return
TB103-9 MNFEO
Fuse Alarm Minor, External, alarm causes
open
TB103-10 PMNVC Power Minor Visual, alarm causes closure
TB103-11 PMNVR Power Minor Visual, return
TB103-12 PMNVO Power Minor Visual, alarm causes open
TB104-1 PMJAC Power Major Audible, alarm causes closure
TB104-2 PMJAR Power Major Audible, return
TB104-3 PMJAO Power Major Audible, alarm causes open
Table 4-F: CP1 Terminal Block Pin Assignments
for 113B Control Unit
Pin
Number
Designation Definition
