Lucent Technologies Lineage
®
2000 ECS-12U Controller J85501E-2
4 - 28 Installation and Setup Issue 3 July 1998
Figure 4-14: Typical Alarm Application Schematic
Battery
Disconnect
Bulk Ringer
Alarm
Minor Alarm
Major Alarm
1K Ohm
4.64K Ohm
4.64K Ohm
Return
-48V
-48V
-48V
Return
DG
OS
RMN
RMJ
113B Control Unit
RMN and RMJ are general purpose alarm inputs that can
be used for auxiliary equipment.
TB101
1
3
4
5
