Lucent Technologies Lineage
®
2000 ECS-12U Controller J85501E-2
4 - 30 Installation and Setup Issue 3 July 1998
External Wiring
NOTE The ECS-12U Controller may provide false alarms if
rectifier interface cables are connected to the controller and
are not connected to the respective rectifiers.
Micro
rocessor
and Datalo
er
Boards
See Product Manual 167-790-109, Lineage
®
2000 ECS
Controller Options, for installation, wiring, and use of the
optional expansion boards.
Circuit Pack
Installation
When replacing a circuit pack or adding a new circuit pack to a
controller which is in service, the circuit pack hardware must
first be set up as described in “Basic Hardware Setup”
in this
section.
WARNING Circuit packs can be damaged by static electricity.
Operators should always be grounded when handling circuit
packs. Connect the grounding wriststrap to the ESD ground
plug on the controller front panel.
To install a circuit pack, simply open the controller front panel,
pull out the drawer, and slide the board along its guide rails into
the proper backplane connectors. Backplane connectors are
arranged so that circuit packs cannot be inserted in the wrong
slots. It is not necessary to pull fuses or power down the plant or
controller in any manner to remove or add any circuit packs in
the controller.
Re
lacement o
Multi
lexin
Board
If the multiplexing board (BCC1, see Figure 4-16) must be
replaced, use the following procedure:
1. Open the front cover, and pull out the drawer. Unplug any
field wiring connected to CP1, CP2, or CP3 by lifting the
terminal blocks off the board.
2. Lifting the front of the drawer, pull it out of the controller
chassis completely and unplug the two ribbon cables at the
multiplexing board BCC1 (P705 and P706) and the green
ground lead.
